RM0365
22.6.16

TIM16 option register (TIM16_OR)

Address offset: 0x50
Reset value: 0x0000 0000
31 30 29
Res Res Res
15 14 13
Res Res Res
Bits 31:2 Reserved, must be kept at reset value.
Bits1:0 TI1_RMP: Timer 16 input 1 connection.
This bit is set and cleared by software.
00: TIM16 TI1 is connected to GPIO
01: TIM16 TI1 is connected to RTC_clock
10: TIM16 TI1 is connected to HSE/32
11: TIM16 TI1 is connected to MCO
28 27 26 25
Res Res Res Res
12 11 10 9
Res Res Res Res
General-purpose timers (TIM15/TIM16/TIM17)
24 23 22
Res Res Res
8 7 6
Res Res Res
DocID025202 Rev 7
21 20 19 18
Res Res Res Res
5 4 3 2
Res Res Res Res
17 16
Res Res
1 0
TI1RMP
rw rw
