Analog-to-digital converters (ADC)
15.4

ADC interrupts

For each ADC, an interrupt can be generated:
After ADC power-up, when the ADC is ready (flag ADRDY)
On the end of any conversion for regular groups (flag EOC)
On the end of a sequence of conversion for regular groups (flag EOS)
On the end of any conversion for injected groups (flag JEOC)
On the end of a sequence of conversion for injected groups (flag JEOS)
When an analog watchdog detection occurs (flag AWD1, AWD2 and AWD3)
When the end of sampling phase occurs (flag EOSMP)
When the data overrun occurs (flag OVR)
When the injected sequence context queue overflows (flag JQOVF)
Separate interrupt enable bits are available for flexibility.
ADC ready
End of conversion of a regular group
End of sequence of conversions of a regular group
End of conversion of a injected group
End of sequence of conversions of an injected group
Analog watchdog 1 status bit is set
Analog watchdog 2 status bit is set
Analog watchdog 3 status bit is set
End of sampling phase
Overrun
Injected context queue overflows
355/1080

Table 94. ADC interrupts per each ADC

Interrupt event
DocID025202 Rev 7
Event flag
Enable control bit
ADRDY
ADRDYIE
EOC
EOCIE
EOS
EOSIE
JEOC
JEOCIE
JEOS
JEOSIE
AWD1
AWD1IE
AWD2
AWD2IE
AWD3
AWD3IE
EOSMP
EOSMPIE
OVR
OVRIE
JQOVF
JQOVFIE
