RM0365
29.8.9

Interrupt flag clear register (USART_ICR)

Address offset: 0x20
Reset value: 0x0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. EOBCF RTOCF
rc_w1
Bits 31:21 Reserved, must be kept at reset value.
Bit 20 WUCF: Wakeup from Stop mode clear flag
Note: If the USART does not support the wakeup from Stop feature, this bit is reserved and
Bits 19:18 Reserved, must be kept at reset value.
Bit 17 CMCF: Character match clear flag
Bits 16:13 Reserved, must be kept at reset value.
Bit 12 EOBCF: End of block clear flag
Note: If the USART does not support Smartcard mode, this bit is reserved and forced by
Bit 11 RTOCF: Receiver timeout clear flag
Note: If the USART does not support the Receiver timeout feature, this bit is reserved and
Bit 10 Reserved, must be kept at reset value.
Bit 9 CTSCF: CTS clear flag
Note: If the hardware flow control feature is not supported, this bit is reserved and forced by
Bit 8 LBDCF: LIN break detection clear flag
Note: If LIN mode is not supported, this bit is reserved and forced by hardware to '0'. Please
Bit 7 Reserved, must be kept at reset value.
Bit 6 TCCF: Transmission complete clear flag
Bit 5 Reserved, must be kept at reset value.
Bit 4 IDLECF: Idle line detected clear flag
Universal synchronous asynchronous receiver transmitter (USART)
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. CTSCF LBDCF
rc_w1 rc_w1
Writing 1 to this bit clears the WUF flag in the USART_ISR register.
forced by hardware to '0'.
Writing 1 to this bit clears the CMF flag in the USART_ISR register.
Writing 1 to this bit clears the EOBF flag in the USART_ISR register.
hardware to '0'. Please refer to
Writing 1 to this bit clears the RTOF flag in the USART_ISR register.
forced by hardware to '0'. Please refer to
page 837.
Writing 1 to this bit clears the CTSIF flag in the USART_ISR register.
hardware to '0'. Please refer to
Writing 1 to this bit clears the LBDF flag in the USART_ISR register.
refer to Section 29.4: USART implementation on page
Writing 1 to this bit clears the TC flag in the USART_ISR register.
Writing 1 to this bit clears the IDLE flag in the USART_ISR register.
24 23 22
Res. Res. Res.
8 7 6
Res. TCCF
rc_w1 rc_w1
Section 29.4: USART implementation on page
Section 29.4: USART implementation on
Section 29.4: USART implementation on page
DocID025202 Rev 7
21 20 19 18
Res. WUCF Res. Res.
rc_w1
5 4 3 2
Res. IDLECF ORECF NCF
rc_w1 rc_w1 rc_w1
837.
17 16
CMCF Res.
rc_w1
1 0
FECF PECF
rc_w1 rc_w1
837.
837.
898/1080
