RM0365
Bit 2 RE: Receiver enable
This bit enables the receiver. It is set and cleared by software.
0: Receiver is disabled
1: Receiver is enabled and begins searching for a start bit
Bit 1 UESM: USART enable in Stop mode
When this bit is cleared, the USART is not able to wake up the MCU from Stop mode.
When this bit is set, the USART is able to wake up the MCU from Stop mode, provided that
the USART clock selection is HSI or LSE in the RCC.
This bit is set and cleared by software.
0: USART not able to wake up the MCU from Stop mode.
1: USART able to wake up the MCU from Stop mode. When this function is active, the clock
source for the USART must be HSI or LSE (see
Note: It is recommended to set the UESM bit just before entering Stop mode and clear it on
Bit 0 UE: USART enable
When this bit is cleared, the USART prescalers and outputs are stopped immediately, and
current operations are discarded. The configuration of the USART is kept, but all the status
flags, in the USART_ISR are set to their default values. This bit is set and cleared by
software.
0: USART prescaler and outputs disabled, low-power mode
1: USART enabled
Note: In order to go into low-power mode without generating errors on the line, the TE bit
29.8.2
Control register 2 (USART_CR2)
Address offset: 0x04
Reset value: 0x0000
31
30
29
ADD[7:4]
rw
rw
rw
15
14
13
SWAP
LINEN
STOP[1:0]
rw
rw
rw
Universal synchronous asynchronous receiver transmitter (USART)
exit from Stop mode.
If the USART does not support the wakeup from Stop feature, this bit is reserved and
forced by hardware to '0'. Please refer to
page
837.
must be reset before and the software must wait for the TC bit in the USART_ISR to be
set before resetting the UE bit.
The DMA requests are also reset when UE = 0 so the DMA channel must be disabled
before resetting the UE bit.
28
27
26
25
ADD[3:0]
rw
rw
rw
rw
12
11
10
9
CLKEN
CPOL
CPHA
rw
rw
rw
rw
Section 29.4: USART implementation on
24
23
22
RTOEN
ABRMOD[1:0]
rw
rw
rw
8
7
6
LBCL
Res.
LBDIE
rw
rw
DocID025202 Rev 7
Section Reset and clock control (RCC)
21
20
19
MSBFI
ABREN
DATAINV TXINV
RST
rw
rw
rw
5
4
3
LBDL
ADDM7
Res.
rw
rw
.
18
17
16
RXINV
rw
rw
rw
2
1
0
Res.
Res.
Res.
882/1080
901
