Inter-integrated circuit (I2C) interface
28.7.6

Timeout register (I2C_TIMEOUTR)

Address offset: 0x14
Reset value: 0x0000 0000
Access: No wait states, except if a write access occurs while a write access to this register is
ongoing. In this case, wait states are inserted in the second write access until the previous
one is completed. The latency of the second write access can be up to 2 x PCLK1 + 6 x
I2CCLK.
31 30 29
TEXTEN Res. Res.
rw
15 14 13
TIMOUTEN Res. Res.
rw
Bit 31 TEXTEN: Extended clock timeout enable
0: Extended clock timeout detection is disabled
1: Extended clock timeout detection is enabled. When a cumulative SCL stretch for more
than t
Bits 30:28 Reserved, must be kept at reset value.
Bits 27:16 TIMEOUTB[11:0]: Bus timeout B
This field is used to configure the cumulative clock extension timeout:
In master mode, the master cumulative clock low extend time (t
In slave mode, the slave cumulative clock low extend time (t
t
LOW:EXT
Note: These bits can be written only when TEXTEN=0.
Bit 15 TIMOUTEN: Clock timeout enable
0: SCL timeout detection is disabled
1: SCL timeout detection is enabled: when SCL is low for more than t
high for more than t
Bits 14:13 Reserved, must be kept at reset value.
Bit 12 TIDLE: Idle clock timeout detection
0: TIMEOUTA is used to detect SCL low timeout
1: TIMEOUTA is used to detect both SCL and SDA high timeout (bus idle condition)
Note: This bit can be written only when TIMOUTEN=0.
Bits 11:0 TIMEOUTA[11:0]: Bus Timeout A
This field is used to configure:
– The SCL low timeout condition t
t
– The bus idle condition (both SCL and SDA high) when TIDLE=1
t
Note: These bits can be written only when TIMOUTEN=0.
Note:
If the SMBus feature is not supported,
"0x00000000".
827/1080
28 27 26
Res.
12 11 10
TIDLE
rw
is done by the I2C interface, a timeout error is detected (TIMEOUT=1).
LOW:EXT
= (TIMEOUTB+1) x 2048 x t
(TIDLE=1), a timeout error is detected (TIMEOUT=1).
IDLE
= (TIMEOUTA+1) x 2048 x t
TIMEOUT
= (TIMEOUTA+1) x 4 x t
IDLE
Please refer to Section 28.3: I2C
DocID025202 Rev 7
25 24 23 22
TIMEOUTB [11:0]
rw
9 8 7 6
TIMEOUTA [11:0]
rw
I2CCLK
when TIDLE=0
TIMEOUT
I2CCLK
I2CCLK
this register is reserved and forced by hardware to
implementation.
21 20 19 18
5 4 3 2
) is detected
LOW:MEXT
) is detected
LOW:SEXT
(TIDLE=0) or
TIMEOUT
RM0365
17 16
1 0
