33.14.2

Debug support for timers, watchdog, bxCAN and I

During a breakpoint, it is necessary to choose how the counter of timers and watchdog
should behave:
•
They can continue to count inside a breakpoint. This is usually required when a PWM is
controlling a motor, for example.
• They can stop to count inside a breakpoint. This is required for watchdog purposes.
For the bxCAN, the user can choose to block the update of the receive register during a
breakpoint.
2
For the I
For timers having complementary outputs, when the counter is stopped
(DBG_TIMx_STOP=1), the outputs are disabled (as if the MOE bit was reset) for safety
purposes.
33.14.3

Debug MCU configuration register

This register allows the configuration of the MCU under DEBUG. This concerns:
• Low-power mode support
•
Timer and watchdog counter support
• bxCAN communication support
•
Trace pin assignment
This DBGMCU_CR is mapped on the External PPB bus at address 0xE0042004.
It is asynchronously reset by the PORESET (and not the system reset). It can be written by
the debugger under system reset.
If the debugger host does not support these features, it is still possible for the user software
to write to these registers.
DBGMCU_CR
Address: 0xE004 2004
Only 32-bit access supported
POR Reset: 0x0000 0000 (not reset by system reset)
31 30 29
Res Res Res
15 14 13
Res Res Res
C, the user can choose to block the SMBUS timeout during a breakpoint.
28 27 26 25
Res Res Res Res
12 11 10 9
Res Res Res Res
DocID025202 Rev 7
24 23 22 21
Res Res Res Res
8 7 6 5
TRACE_ TRACE
Res MODE _
[1:0] IOEN
rw rw rw
Debug support (DBG)
2
C
20 19 18 17
Res Res Res Res
4 3 2 1
DBG_
DBG_
Res. Res STAND
STOP
BY
rw rw
16
Res
0
DBG_
SLEEP
rw

1054/1080
