15.5.15

ADC injected sequence register (ADCx_JSQR, x=1

Address offset: 0x4C
Reset value: 0x0000 0000
31 30 29
Res. JSQ4[4:0]
rw rw
15 14 13
JSQ2[1:0] Res.
rw rw
Bit 31 Reserved, must be kept at reset value.
Bits 30:26 JSQ4[4:0]: 4th conversion in the injected sequence
These bits are written by software with the channel number (1..18) assigned as the 4th in the
injected conversion sequence.
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Note: Analog input channel 0 is not mapped: value "00000" should not be used
Bit 25 Reserved, must be kept at reset value.
Bits 24:20 JSQ3[4:0]: 3rd conversion in the injected sequence
These bits are written by software with the channel number (1..18) assigned as the 3rd in the
injected conversion sequence.
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Note: Analog input channel 0 is not mapped: value "00000" should not be used
Bit 19 Reserved, must be kept at reset value.
Bits 18:14 JSQ2[4:0]: 2nd conversion in the injected sequence
These bits are written by software with the channel number (1..18) assigned as the 2nd in the
injected conversion sequence.
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Note: Analog input channel 0 is not mapped: value "00000" should not be used
Bit 13 Reserved, must be kept at reset value.
Bits 12:8 JSQ1[4:0]: 1st conversion in the injected sequence
These bits are written by software with the channel number (1..18) assigned as the 1st in the
injected conversion sequence.
Note: Software is allowed to write these bits at any time, once the ADC is enabled (ADEN=1).
Note: Analog input channel 0 is not mapped: value "00000" should not be used
28 27 26 25
Res.
rw rw rw
12 11 10 9
JSQ1[4:0]
rw rw rw rw
DocID025202 Rev 7
Analog-to-digital converters (ADC)
24 23 22 21
JSQ3[4:0]
rw rw rw rw
8 7 6 5
JEXTEN[1:0]
rw rw rw
2)
..
20 19 18 17
Res. JSQ2[4:2]
rw rw rw
4 3 2 1
JEXTSEL[3:0]
rw rw rw rw
16
rw
0
JL[1:0]
rw
