Table 6. Flash Module Organization - STMicroelectronics RM0365 Reference Manual

RM0365
Flash area
Main memory
Information block
Flash memory
interface registers
1. The gray color is used for reserved Flash memory addresses.
The information block is divided into two parts:
•
System memory is used to boot the device in System memory boot mode. The area is
reserved for use by STMicroelectronics and contains the boot loader which is used to
reprogram the Flash memory through one of the following interfaces: USART1,
USART2 or USB (DFU). It is programmed by ST when the device is manufactured, and
protected against spurious write/erase operations. For further details, please refer to
the AN2606 available from www.st.com.
•
Option bytes

Table 6. Flash module organization

Flash memory addresses
0x0800 0000 - 0x0800 07FF
0x0800 0800 - 0x0800 0FFF
0x0800 1000 - 0x0800 17FF
0x0800 1800 - 0x0800 1FFF
.
.
.
.
.
.
.
.
0x0803 F800 - 0x0807 FFFF
0x1FFF D800 - 0x1FFF F7FF
0x1FFF F800 - 0x1FFF F80F
0x4002 2000 - 0x4002 2003
0x4002 2004 - 0x4002 2007
0x4002 2008 - 0x4002 200B
0x4002 200C - 0x4002 200F
0x4002 2010 - 0x4002 2013
0x4002 2014 - 0x4002 2017
0x4002 2018 - 0x4002 201B
0x4002 201C - 0x4002 201F
0x4002 2020 - 0x4002 2023
DocID025202 Rev 7
Embedded Flash memory
(1)
Size
Name
(bytes)
2 K Page 0
2 K Page 1
2 K Page 2
2 K Page 3
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
2 K Page 255
8 K System memory
16 Option bytes
4 FLASH_ACR
4 FLASH_KEYR
4 FLASH_OPTKEYR
4 FLASH_SR
4 FLASH_CR
4 FLASH_AR
4 Reserved
4 FLASH_OBR
4 FLASH_WRPR
