■ I Flag
A flag that specifies whether an interrupt is permitted or prohibited. This flag is provided as bit4
of the PS register.
Table 3.10-2 shows the functions of I flag.
Table 3.10-2 Functions of I Flag
Value
0
1
■ Interrupt Level Mask (ILM) Register
A PS register (bit20 to bit16) that holds an interrupt level mask value.
The CPU accepts only an interrupt request sent to it with an interrupt level higher than the level
indicated by the ILM.
The highest level is 0 (00000
Values that can be set by a program have a limit. If the original value is between 16 and 31, the
new value must be between 16 and 31. If an instruction that sets a value between 0 and 15 is
executed, the specified value plus 16 is transferred.
If the original value is between 0 and 15, any value between 0 and 31 may be set.
Note:
Use the ST ILM instruction to set this register.
■ Level Mask for Interrupt and NMI
If an NMI or interrupt request occurs, the interrupt level (Table 3.10-1) of the interrupt source is
compared with the level mask value held in the ILM. A request meeting the following condition is
masked and is not accepted:
Interrupt level of cause ≥ Level mask value
Interrupts prohibited
Cleared to "0" if the INT instruction is executed.
Note that a value saved on the stack is the value before it is cleared.
Interrupts permitted
The mask processing of an interrupt request is controlled by the value in the
ILM register.
) and the lowest level is 31 (11111
B
