9.2.6 Buffer Management
9.2.6.1
Data Buffer
The SD/SDIO host controller uses a data buffer. This buffer transfers data from one data bus
(Interconnect) to another data bus (SD, SDIO card bus) and vice versa.
The buffer is the heart of the interface and ensures the transfer between the two interfaces (L4 and the
card). To enhance performance, the data buffer is completed by a prefetch register and a post-write
buffer that are not accessible by the host controller.
The read access time of the prefetch register is faster than the one of the data buffer. The prefetch
register allows data to be read from the data buffer at an increased speed by preloading data into the
prefetch register.
The entry point of the data buffer, the prefetch buffer, and the post-write buffer is the 32-bit register
SD_DATA. A write access to the SD_DATA register followed by a read access from the SD_DATA
register corresponds to a write access to the post-write buffer followed by a read access to the prefetch
buffer. As a consequence, it is normal that the data of the write access to the SD_DATA register and
the data of the read access to the SD_DATA register are different.
The number of 32-bit accesses to the SD_DATA register that are needed to read (or write) a data block
with a size of SD_BLK[10:0] BLEN, and equals the rounded up result of BLEN divided by 4. The
maximum block size supported by the host controller is hard-coded in the register SD_CAPA[17:16]
MBL field and cannot be changed.
A read access to the SD_DATA register is allowed only when the buffer read enable status is set to 1
(SD_PSTATE[11] BRE); otherwise, a bad access (SD_STAT[29] BADA) is signaled.
A write access to the SD_DATA register is allowed only when the buffer write enable status is set to 1
(SD_PSTATE[10] BWE); otherwise, a bad access (SD_STAT[29] BADA) is signaled and the data is not
written.
The data buffer has two modes of operation to store and read of the first and second portions of the
data buffer:
•
When the size of the data block to transfer is less than or equal to MEM_SIZE/2 (in double
buffering), two data transfers can occur from one data bus to the other data bus and vice versa at
the same time. The SD/SDIO controller uses the two portions of the data buffer in a ping-pong
manner so that storing and reading of the first and second portions of the data buffer are
automatically interchanged from time to time so that data may be read from one portion (for
instance, through a DMA read access on the interconnect bus) while data (for instance, from the
card) is being stored into the other portion and vice versa. When BLEN is less than or equal to 200h
(that is, less or equal to 512Bytes), each of the two portions of the buffer that can be used have a
size of BLEN (that is, 32-bits x BLEN div by 4). Not more than this total size of 2 times 32-bits ×
BLEN div by 4 can be used.
•
When the size of the data block to transfer is larger than MEM_SIZE/2, only one data transfer can
occur from one data bus to the other data bus at a time. The SD/SDIO host controller uses the
entire data buffer as a single portion. In this mode, a bad access (SD_STAT[29] BADA) is signaled
when two data transfers occur from one data bus to the other data bus and vice versa at the same
time.
The SD_CMD[4] DDIR bit must be configured before a transfer to indicate
the direction of the transfer.
Figure 9-11
shows the buffer management for writing and
for reading.
942
Secure Digital (SD)/—Secure Digital I/O (SDIO) Card Interface
Preliminary
CAUTION
Figure 9-12
© 2011, Texas Instruments Incorporated
www.ti.com
shows the buffer management
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
