Registers

14.7.4.30 CM_TIMER6_CLKSEL Register

The CM_TIMER6_CLKSEL register selects the Mux select line for TIMER6 clock. It is shown and
described in the figure and table below
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Bit
Field
31-2
Reserved
1-0
CLKSEL

14.7.4.31 CM_SYSCLK23_CLKSEL Register

The CM_SYSCLK23_CLKSEL register selects the divider value for SYSCLK23. It is shown and
described in the figure and table below.
31
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 14-63. CM_SYSCLK23_CLKSEL Register Field Descriptions
Bit
Field
31-3
Reserved
2-0
CLKSEL
1446
Power, Reset, and Clock Management (PRCM) Module
Preliminary
Figure 14-47. CM_TIMER6_CLKSEL Register
Reserved
R-0
Table 14-62. CM_TIMER6_CLKSEL Register Field Descriptions
Value
Description
0
Reserved
Selects the Mux select line for TIMER6 clock [warm reset insensitive]
0
Select TIMER clock to be TCLKIN
1h
Select TIMER clock to be external 32 KHz clock.(After MUX)
2h
Select TIMER clock to be CLKIN
3h
Reserved
Figure 14-48. CM_SYSCLK23_CLKSEL Register
Reserved
R-0
Value
Description
0
Reserved
Selects the divider value [warm reset insensitive]
0
Select SYS_CLK divided by 1
1h
Select SYS_CLK divided by 2
2h
Select SYS_CLK divided by 3
3h
Select SYS_CLK divided by 4
4h
Select SYS_CLK divided by 5
5h
Select SYS_CLK divided by 6
6h
Select SYS_CLK divided by 7
7h
Select SYS_CLK divided by 8
© 2011, Texas Instruments Incorporated
www.ti.com
2
1
0
CLKSEL
R/W-1
3
2
0
CLKSEL
R/W-0
SPRUGX9 – 15 April 2011
Submit Documentation Feedback
