Programming Guide | VLT® AutomationDrive FC 301/FC 302
45-32 Alarm Mode
Default value: [0] Absolute
Setup: 2 setups
Data type: Uint8
Select a mode to define the threshold limits for alarms.
Option Name
[0]* Absolute
[1] Offset
[2] Factor
The values can be specified in parameter 45-33 Alarm High and parameter 45-38 Alarm Low. For example, if selecting [0] Absolute,
setting an alarm low value of 200, and an alarm high value of 300, the threshold limit for alarms ranges from 200 to 300.
Table 67: Parameter Index
Parameter ID
45-32.0
45-32.1
45-32.2
45-32.3
45-33 Alarm High
Default value:
Size related
Setup: 2 setup
Data type:
Uint16
Type the threshold value for high alarm notification. Based on the type of alarm mode selected by the user, a high alarm threshold is
calculated.
Table 68: Options
Parameter ID
45-33.0
45-33.1
45-33.2
45-33.3
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Description
Absolute value is considered as threshold.
Calculates threshold as a sum of the computed baseline data and
the offset values.
Calculates threshold as baseline data * factor.
Description
Stator Winding
Load Envelope
Sensor 1 Vibration
Sensor 2 Vibration
Parameter type:
Conversion index:
Change during operation:
Description
Stator Winding
Load Envelope
Sensor 1 Vibration
Sensor 2 Vibration
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Option, Array [6]
–
True
Range, 0 - 100%, Array [6]
-2
True
