Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[100] RS Flipflop 6
[101] RS Flipflop 7
[102] Relay 1
[103] Relay 2
[104] Relay 3
[105] Relay 4
[106] Relay 5
[107] Relay 6
[108] Relay 7
[109] Relay 8
[110] Relay 9
[212] Emergency mode
[222] Homing OK
[223] On target
[224] Position error
© 2024.09
Description
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
X47/VLT® Extended Relay Card MCB 113.
X47/VLT® Extended Relay Card MCB 113.
X47/VLT® Extended Relay Card MCB 113.
X47/VLT® Extended Relay Card MCB 113.
X34/VLT® Relay Card MCB 105.
X34/VLT® Relay Card MCB 105.
X34/VLT® Relay Card MCB 105.
NOTICE
This option is only available with software version 48.2X or
newer.
Homing is completed with the selected homing function
(parameter 17-80 Homing Function).
NOTICE
This option is only available with software version 48.2X or
newer.
Positioning is completed and the on target signal is sent when
the actual position is within parameter 3-05 On Reference
Window for the duration of parameter 3-09 On Target Time and
the actual speed does not exceed parameter 3-05 On Reference
Window.
NOTICE
This option is only available with software version 48.2X or
newer.
The position error exceeds the value in parameter 4-71 Maximum
Position Error for the time set in parameter 4-72 Position Error
Timeout.
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
459
