Programming Guide | VLT® AutomationDrive FC 301/FC 302
Forces the duplex for each port to full or half duplex. If parameter 12-12 Auto Negotiation is set to [1] On, this parameter is read-only.
Option Name
[0] Half duplex
[1] Full duplex
12-18 Supervisor MAC
Default value: 0
Setup: 2 setups
Data type:
OctStr[6]
MAC addresses of currently active supervisors.
12-19 Supervisor IP Addr.
Default value: 0
Setup:
2 setups
Data type: OctStr[4]
IP addresses of currently active supervisors.

12-2* Process Data

6.13.3
12-20 Control Instance
Default value:
Size related
Setup: 1 setup
Data type:
Uint8
This parameter is read-only. It shows the connection to the master.
In Ethernet/IP: If no CIP connection is present, None is shown.
l
In EtherCAT: If no connection is active, None is shown, otherwise it shows the active PDO.
l
In POWERLINK: If no connection is active, None is shown, otherwise it shows the active PDO (23).
l
12-21 Process Data Config Write
Default value:
Size related
Setup: All setups
Data type: Uint16
© 2024.09
Description
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Range, 0 - 2147483647, Array
[2]
0
True
Range, 0 - 2147483647, Array
[2]
0
True
Range, 0 - 255
0
True
Option, Array [81]
–
True
397
