Programming Guide | VLT® AutomationDrive FC 301/FC 302
Selected
event
Relay
output
On delay
P 5-41
Selected
event
Relay
output
On delay
P 5-41
Figure 67: On Delay, Relay
5-42 Off Delay, Relay
Default value: 0.01 s
Setup: All setups
Data type: Uint16
Enter the delay of the relay cutout time. Select 1 of 2 internal mechanical relays in an array function. See parameter 5-40 Function Relay
for details. If the selected event condition changes before a delay timer expires, the relay output is unaffected.
Selected
event
Relay
output
On delay
P 5-41
Figure 68: Off Delay, Relay

5-5* Pulse Input

6.7.5
The following parameters are only available in FC 302:
Parameter 5-50 Term. 29 Low Frequency
l
Parameter 5-51 Term. 29 High Frequency
l
Parameter 5-52 Term. 29 Low Ref./Feedb. Value
l
Parameter 5-53 Term. 29 High Ref./Feedb. Value
l
Parameter 5-54 Pulse Filter Time Constant #29
l
© 2024.09
Off delay
P 5-42
Off delay
P 5-42
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter Descriptions
Range, 0.01 - 600 s, Array [9]
-2
True
AU275636650261en-003201 / 130R0334 | 263
