Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 35: 5-30 Digital Outputs - 2
Option
[227] Touch activated
[228] Touch sensor found
[229] Vir. master on ref.
[231] In power lim. mot.
[232] In power lim. gen.
[233] In power limit
[234] PE power off
[246] Emcy mode was act.
[247] Emergency mode
[249] Emcy m. OPR unexpected
[250] Emcy mode limits
[254] Testing emcy mode
5-30 Terminal 27 Digital Output
Default value:
–
Setup: All setups
Data type:
Uint8
Select the function from the available digital output range and the additional options [60] Counter A (up), [61] Counter A (down), [63]
Counter B (up), and [64] Counter B (down). Counters are used in smart logic control functions. All functions are described in
Table 35.
244 | © 2024.09
(continued)
Function
NOTICE
This option is only available with software version 48.XX.
Touch probe positioning is active. The drive monitors the touch
probe sensor input.
NOTICE
This option is only available with software version 48.XX.
The touch sensor has been detected.
NOTICE
This option is only available with software version 48.XX.
The virtual master is running on the set reference.
The drive has been operating in emergency mode.
The drive is operating in emergency mode. See parameter group
24-0* Emergency Mode.
Emergency mode input or safe stop is not operating as expected,
for example, live zero monitoring on an analog input is activated.
During emergency mode operation, 1 of the critical alarms has
been activated and suppressed by emergency mode. This may
lead to reduced drive performance and expected operation life-
time before service is required.
Emergency mode is activated in a special test mode where the
drive stops on all alarms.
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
Option
–
True
Table 33
AU275636650261en-003201 / 130R0334
and
