Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[1] Mean
[2] Maximum/minimum
[3]* Mean +/- 3 standard deviation
Table 65: Parameter Index
Parameter ID
45-30.0
45-30.1
45-30.2
45-30.3
45-31 Warning Mode
Default value:
[0] Absolute
Setup: 2 setups
Data type:
Uint8
Select a mode to define threshold limit for warnings.
Option Name
[0]* Absolute
[1] Offset
[2] Factor
The values can be specified in parameter 45-34 Warning S2 High, parameter 45-35 Warning S1 High, Parameter 45-36 Warning S1 Low,
and parameter 45-37 Warning S2 Low. For example, if selecting [0] Absolute, a warning S2 low value of 200, and a warning S1 high value
of 300, the threshold limit for warning stage 2 ranges from 200–300.
Table 66: Parameter Index
Parameter ID
45-31.0
45-31.1
45-31.2
45-31.3
768 | © 2024.09
Description
Average of the baseline data is shown.
Maximum and minimum of the baseline data is shown.
Mean and +/-3 standard deviations of the baseline data is shown.
Description
Stator Winding
Load Envelope
Sensor 1 Vibration
Sensor 2 Vibration
Parameter type:
Conversion index:
Change during operation:
Description
Absolute value is considered as threshold limit.
Calculates threshold as a sum of the computed baseline data and
the offset values.
Calculates threshold as baseline data x factor.
Description
Stator Winding
Load Envelope
Sensor 1 Vibration
Sensor 2 Vibration
Parameter Descriptions
Option
–
True
