Programming Guide | VLT® AutomationDrive FC 301/FC 302
729RPM 6.21A
Load depen. setting
1 - 60 Low speed load
c ompensation
1 0% 6
Figure 20: Saving a Data Value

Infinitely Variable Change of Numeric Data Value

5.1.17
If the selected parameter shows a numeric data value, select a digit with [◄] [►].
635 RP M 0.44 A
Star t Adjustmen t s
1 - 71 S tar t D ela y
00. 0 s
Figure 21: Selecting a Digit
Change the selected digit infinitely variably with [▲] [▼]. The cursor indicates the selected digit. Place the cursor on the digit to save
and press [OK].
957 RPM 11.58A
Start Adjustments
1-71 High starting torque time
0. s
4
Figure 22: Saving
5.1.18

Value, Step by Step

Certain parameters can be changed step by step. This applies to:
Parameter 1-20 Motor Power [kW].
l
Parameter 1-22 Motor Voltage.
l
Parameter 1-23 Motor Frequency.
l
The parameters are changed both as a group of numeric data values and as numeric data values that are infinitely varying.
5.1.19

Readout and Programming of Indexed Parameters

Parameters are indexed when placed in a rolling stack. Parameter 15-30 Fault Log: Error Code to parameter 15-32 Alarm Log: Time
contain a fault log, which can be read out. Select a parameter, press [OK], and press the [▲] [▼] keys to scroll through the value log.

Changing Values of Indexed Parameters

5.1.20
Change parameter 3-10 Preset Reference as an example.
