Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 9: Setup Link Example
Index
0
1
2
3
4
0-14 Readout: Edit Set-ups/Channel
Default value: 0
Setup: All setups
Data type: Int32
View the setting of parameter 0-11 Edit Set-up for each of the 4 different communication channels. When the number is shown as a hex
number, as it is in the LCP, each number represents 1 channel. Numbers 1–4 represent a setup number; F means factory setting; and A
means active setup. The channels are, from right to left: LCP, FC bus, USB, HPFB1-5.
Example
The number AAAAAA21h means the following:
The drive received the setting of setup 2 via a fieldbus channel. The selection is reflected in parameter 0-11 Edit Set-up.
l
A user selected setup 1 via the LCP.
l
All other channels are using the active setup.
l
0-15 Readout: Actual Set-up
Default value: 0
Setup: All setups
Data type: Uint8
Makes it possible to read out the active setup, also when [9] Multi Set-up is selected in parameter 0-10 Active Set-up.

0-2* LCP Display

6.2.4
Define the variables shown in the LCP. For information on how to write display texts, refer to:
Parameter 0-37 Display Text 1.
l
Parameter 0-38 Display Text 2.
l
Parameter 0-39 Display Text 3.
l
0-20 Display Line 1.1 Small
Default value: [1617] Speed RPM
Setup:
All setups
Data type: Uint16
© 2024.09
LCP value
{0}
{1,2}
{1,2}
{3}
{4}
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Range, -2147483648–
2147483647
0
False
Range, 0–255
0
False
Option
–
True
