Programming Guide | VLT® AutomationDrive FC 301/FC 302
6-14 Terminal 53 Low Ref./Feedb. Value
Default value: Size related
Setup: All setups
Data type: Int32
Enter the analog input scaling value that corresponds to the low voltage/low current set in parameter 6-10 Terminal 53 Low Voltage and
parameter 6-12 Terminal 53 Low Current.
6-15 Terminal 53 High Ref./Feedb. Value
Default value: Size related
Setup: All setups
Data type:
Int32
Enter the analog input scaling value that corresponds to the maximum reference feedback value set in parameter 6-11 Terminal 53 High
Voltage and parameter 6-13 Terminal 53 High Current.
6-16 Terminal 53 Filter Time Constant
Default value: 0.001 s
Setup: All setups
Data type: Uint16
This parameter cannot be adjusted while the motor is running.
Enter the filter time constant. This constant is a first-order digital low-pass filter time for suppressing electrical noise in terminal 53. A
high value improves dampening but also increases the delay through the filter.
6-2* Analog Input 2
6.8.3
This parameter group contains parameters for configuring the scaling and limits for analog input 2 (terminal 54).
6-20 Terminal 54 Low Voltage
Default value: Size related
Setup:
All setups
Data type: Int16
Enter the low voltage value. This analog input scaling value should correspond to the minimum reference value set in parameter 3-02
Minimum Reference.
6-21 Terminal 54 High Voltage
Default value: 10 V
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Parameter Descriptions
Range, -999999.999
- 999999.999
ReferenceFeedbackUnit
-3
True
Range, -999999.999
- 999999.999
ReferenceFeedbackUnit
-3
True
Range, 0.001 - 10 s
-3
True
Range, -10.00 - par. 6-21 V
-2
True
Range, par. 6-20 V - 10 V
