Programming Guide | VLT® AutomationDrive FC 301/FC 302
To change the setup after a timeout, configure as follows:
Set parameter 0-10 Active Set-up to [9] Multi setup.
l
Select the relevant link in parameter 0-12 This Set-up Linked to.
l
Option Name
[0] Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
[6] Qstop and trip
[7] Select setup 1
[8] Select setup 2
[9] Select setup 3
[10] Select setup 4
[26] Trip
8-05 End-of-Timeout Function
Default value: [1] Resume set-up
Setup: 1 setup
Data type:
Uint8
Select the action after receiving a valid control word following a timeout. This parameter is active only when parameter 8-04 Control
Word Timeout Function is set to:
[7] Setup 1
l
[8] Setup 2
l
© 2024.09
NOTICE
Description
Resumes control via fieldbus (fieldbus or standard), using the
most recent control word.
Freezes output frequency until communication resumes.
Stops with auto restart when communication resumes.
Runs the motor at jog frequency until communication resumes.
Runs the motor at maximum frequency until communication
resumes.
Stops the motor, then resets the drive to restart:
• Via the fieldbus.
• Via [Reset].
• Via a digital input.
This option is only available with software version 48.XX.
Stops the motor with the quick stop ramp (parameter 3-81 Quick
Stop Ramp Time). Perform a reset to restart the drive.
Changes the setup after a control word timeout. If
communication resumes after a timeout, parameter 8-05 End-
of-Timeout Function either resumes the setup used before the
timeout, or retains the setup endorsed by the timeout function.
See [7] Select set-up 1.
See [7] Select set-up 1.
See [7] Select set-up 1.
Only available with VLT® Motion Controller Option MCO 302.
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
NOTICE
Option
–
True
