Table 31: Digital Inputs, Function Descriptions - 4
Option
[126] Follow marker inv
[127] Dir. home sensor
[128] Dir. home sen. inv.
[190] Emcy mode ref bit 0
[191] Emcy mode ref bit 1
[192] Emcy mode ref bit 2
[193] Emcy mode setup bit 0
[194] Emcy mode setup bit 1
[195] Test emcy mode
© 2024.09
(continued)
Function
This option is only available with software version 48.XX.
Normally-closed contact. Serves as input for follower marker sig-
nal during marker synchronization based on the option selected
in parameter 3-33 Sync. Mode & Start Behavior.
This option is only available with software version 48.XX.
Normally open contact for defining the home position at the
same edge of the sensor signal independent of running direc-
tion. Only for the 2 homing types [2] Home Sync and [9] Direction
with Sensor.
This option is only available with software version 48.XX.
Normally closed contact for defining the home position at the
same edge of the sensor signal independent of running direc-
tion. Only for the 2 homing types [2] Home Sync and [9] Direction
with Sensor.
Enables a choice between 1 of the 8 preset reference according
to Table
Enables a choice between 1 of the 8 preset reference according
to
Table
Enables a choice between 1 of the 8 preset reference according
to Table
Switch between emergency mode setup 1 to 4 in parameter
group 24-0* Emergency Mode and parameter group 24-4* Emer-
gency Mode 2 without changing starting setup mode for the rest
of the parameters.
Switch between emergency mode setup 1 to 4 in parameter
group 24-0* Emergency Mode and parameter group 24-4* Emer-
gency Mode 2 without changing starting setup mode for the rest
of the parameters.
Activation of emergency mode via parameter 24-09 Emergency
Mode Alarm Handling, option [2] Trip all alarms/test with stop
on all alarms and in normal operation mode. The test timer is
set in parameter 24-42 Timeout for Emergency Mode Test, and
countdown starts when the test signal is active.
NOTICE
NOTICE
NOTICE
