Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[4] 3.0 kHz
[5] 3.5 kHz
[6] 4.0 kHz
[7] 5.0 kHz
[8] 6.0 kHz
[9] 7.0 kHz
[10] 8.0 kHz
[11] 10.0 kHz
[12] 12.0 kHz
[13] 14.0 kHz
[14] 16.0 kHz
14-02 Switching Pattern Shift Frequency
Default value: Size related
Setup: All setups
Data type:
Uint16
Set the frequency where the switching pattern shifts between SFAVM and 60 AVM. Set a value to keep high-speed motors in SFAVM
mode during ramp-up and during low-speed operation. The value to set is motor-dependent. The pattern shift frequency can be set
when parameter 14-00 Switching Pattern is set to [0] 60 AVM.
14-03 Overmodulation
Default value: –
Setup:
All setups
Data type: Uint8
Overmodulation leads to increased torque ripple as harmonics increase.
© 2024.09
Description
Default switching frequency for 18.5–37 kW [25–50 hp], 200 V,
and 37–200 kW [50–300 hp], 400 V.
Default switching frequency for 5.5–15 kW [7.5–20 hp], 200 V,
and 11–30 kW [15-40 hp], 400 V.
Default switching frequency for 0.25–3.7 kW [0.34–5 hp], 200 V,
and 0.37–7.5 kW [0.5–10 hp], 400 V.
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter Descriptions
Range, 15 - 590 Hz
0
False
Option
–
False
