Programming Guide | VLT® AutomationDrive FC 301/FC 302
12-51 Configured Station Address
Default value: 0
Setup: All setups
Data type: Uint16
This parameter shows the configured station address. The parameter can only be set by the master at power-up.
12-59 EtherCAT Status
Default value: 0
Setup:
All setups
Data type: Uint32
This parameter contains status information on the EtherCAT interface. Each of the 32 bits is linked to a status information of the EtherCAT
interface.
Bits 0–7 contain information from ESC register 0x0130 (AL status).
l
Bits 8–15 are reserved for future use.
l
Bits 16–27 contain information from the ESC register 0x0110 and 0x0111 (DL status).
l
Bits 28–31 are reserved for future use.
l
Table 44: Bit Interpretation
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
© 2024.09
Description
EtherCAT statemachine state
EtherCAT statemachine state
EtherCAT statemachine state
EtherCAT statemachine state
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Bit = [0]
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Range, 0 - 65535
0
True
Range, 0 - 4294967295
0
True
Bit = [1]
Init State
Pre-OP
Safe-OP
Reserved
–
–
–
–
–
–
–
–
–
–
–
–
