Programming Guide | VLT® AutomationDrive FC 301/FC 302
33-44 Positive Software End Limit Active
Default value: [0] Inactive
Setup: 2 setups
Data type: Uint8
When this parameter is set to active, the drive continuously checks whether the target position is above the positive software limit. If the
position is outside the limit, an error is issued and the drive control is switched off.
Option Name
[0]* Inactive
[1] Active
33-45 Time in Target Window
Default value:
0 ms
Setup: 2 setups
Data type:
Uint8
33-46 Target Window LimitValue
Default value: 1
Setup: 2 setups
Data type: Uint16
33-47 Size of Target Window
Default value: 0
Setup:
2 setups
Data type: Uint16
Defines the size of the target window with user unit. A position is only viewed as reached when the actual position is within this window.
33-5* I/O Configuration
6.32.4
33-50 Terminal X57/1 Digital Input
Default value:
[0] No function
Setup: 2 setups
Default value:
Uint8
Option Name
[0]* No function
[1] Home switch no
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Option
–
True
Range, 0 - 10 ms
-3
True
Range, 1 - 10000
0
True
Range, 0 - 10000
0
True
Option
–
True
