Programming Guide | VLT® AutomationDrive FC 301/FC 302
Setup: All setups
Data type: Uint8
Select the physical unit for showing the position values on the LCP.
Option Name
[0]* pu
[1] m
[2] mm
[3] inc
[4] °
[5] rad
[6] %
[7] qc
17-71 Position Unit Scale
Default value: 0
Setup: All setups
Data type:
Int8
Enter the scaling factor for the position values. The scaling function multiplies the readout values by 10
parameter. For example, if x = 2, the value 5 is shown as 500. The elements of the array are:
Index 0 is the scaling factor for readout and settings of position values in parameters or in a fieldbus. Index 1 contains exceptions.
l
Index 1 is the scaling factor for readout of position error (parameter 16-08 Position Error) and for the value of parameter 3-08 On
l
Target Window.
17-72 Position Unit Numerator
Default value: 1024
Setup: All setups
Data type:
Int32
This parameter is the numerator in the equation which defines the relation between 1 motor revolution and physical movement of
machine. Example: Consider a turn table application. The motor makes 10 revolutions when the table makes 1 revolution. The position
unit is a degree. For this setup, enter the following values:
Parameter 17-72 Position Unit Numerator = 360
l
Parameter 17-73 Position Unit Denominator = 10
l
Set the physical unit for position values in parameter 17-70 Position Unit.
© 2024.09
Conversion index:
Change during operation:
Description
Position unit.
Meters.
Millimeters
Increments.
Degrees.
Radian.
Percent.
Quad count, which is ¼ of an encoder pulse when using
quadrature encoder signal.
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
–
False
Range, -5 - 5, Array [4]
0
False
x
, where x is the value of this
Range, -2147483648 -
2147483647
0
False
585
