Programming Guide | VLT® AutomationDrive FC 301/FC 302
Use this function if the speed feedback value readouts on the fieldbus fluctuate. Select [1] Motor Data LP-Filter if the function is required.
A power cycle is required for changes to take effect.
Option Name
[0] Motor data Std-Filt.
[1] Motor data LP-Filter
6.10.2

8-1* Ctrl. Word Settings

8-10 Control Word Profile
Default value: –
Setup:
All setups
Data type: Uint8
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the fieldbus
installed in slot A are visible in the LCP display. For guidelines in selection of [0] FC profile and [1] PROFIdrive profile, refer to the product-
specific design guide. For more guidelines in the selection of [1] PROFIdrive profile, refer to the Installation Guide for the installed
fieldbus.
Option Name
[0] FC profile
[1] PROFIdrive profile
[3] FC motion profile
[5] ODVA
[7] CANopen DSP 402
[8] MCO
[22] PROFIdrive v4_2 profile
© 2024.09
Description
Normal fieldbus readouts.
Filtered fieldbus readouts of the following parameters:
• Parameter 16-10 Power [kW]
• Parameter 16-11 Power [hp]
• Parameter 16-12 Motor Voltage
• Parameter 16-14 Motor current
• Parameter 16-16 Torque [Nm]
• Parameter 16-17 Speed [RPM]
• Parameter 16-22 Torque [%]
• Parameter 16-25 Torque [Nm] High
Parameter type:
Conversion index:
Change during operation:
Description
NOTICE
This option is only available with software version 48.XX.
Assigns motion-specific functions to various control and status
word bits. This option is available when [9] Positioning or [10]
Synchronization is selected in parameter 1-00 Configuration
Mode.
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Option
–
True
319
