Programming Guide | VLT® AutomationDrive FC 301/FC 302
42-1* Speed Monitoring
6.37.3
42-10 Measured Speed Source
Default value: Size related
Setup: 1 setup
Data type: Uint8
Option Name
[0] None
[1] Safe option
42-11 Encoder Resolution
Default value: 1024
Setup:
1 setup
Data type: Uint16
Encoder or proximity switch resolution of the encoder connected to the MCB 150 TTL and MCB 151 HTL.
42-12 Encoder Direction
Default value: [0] Clockwise
Setup: 1 setup
Data type: Uint8
Option Name
[0]* Clockwise
[1] Counterclockwise
42-13 Gear Ratio
Default value: 1
Setup:
1 setups
Data type: Uint32
Ratio between motor speed and encoder speed.
Only use when the drive is gear-mounted.
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter Descriptions
Option
–
False
Range, 1 - configuration
dependent
0
False
Option
–
False
Range, 0.0001 - 1000.0000
0
True
