Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[6] Switch to open loop
[7] Select setup 1
[8] Select setup 2
[9] Select setup 3
[10] Select setup 4
[11] Stop & trip
[12] Trip/warning
[13] Trip/catch
17-67 Raw Inc. Quad Counter
Default value:
0
Setup: All setups
Data type:
Uint16
This parameter is only available with software version 48.9X.
Shows the raw incremental counter value in quad counts (4 times pulse count) of an encoder connected to VLT® Encoder Input MCB 102.
It can be an incremental encoder or the incremental part of a dual-channel absolute encoder. MCB 102 must be selected as feedback
source in parameter 1-02 Flux Motor Feedback Source, parameter 7-00 Speed PID Feedback Source, or parameter 7-90 Position PI
Feedback Source.
17-68 Raw Abs. Pos. Low
Default value:
0
Setup: All setups
Data type:
Uint32
This parameter is only available with software version 48.9X.
Shows the least significant 32 bits of the position value read from an absolute encoder connected to VLT® Encoder Input MCB 102. MCB
102 must be selected as feedback source in parameter 1-02 Flux Motor Feedback Source, parameter 7-00 Speed PID Feedback Source, or
parameter 7-90 Position PI Feedback Source.
17-7* Position Scaling
6.18.7
Parameters in this group define how the drive scales and handles the position values.
17-70 Position Unit
Default value: [0] pu
584 | © 2024.09
Description
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Parameter Descriptions
Range, 0 - 65535
0
False
Range, 0 - 2147483647
0
False
Option
AU275636650261en-003201 / 130R0334
