Programming Guide | VLT® AutomationDrive FC 301/FC 302
Data type: Uint8
Option Name
[0] Off
[1]* On
32-38 Absolute Encoder Cable Length
Default value: 0 m
Setup:
2 setups
Data type: Uint16
Set the total cable length (in meters) to avoid that the absolute encoder (SSI) signals come out of synchronization due to signal delays
caused by long encoder cables. VLT® Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 compensate for the
cable delay when the cable length is known.
32-39 Encoder Monitoring
Default value: [0] Off
Setup: 2 setups
Data type:
Uint8
Option Name
[0]* Off
[1] 3 channels
[2] 2 channels
[3] Warning
[4] Alarm
32-40 Encoder Termination
Default value: [1] On
Setup:
2 setups
Data type: Uint8
Option Name
[0] Off
[1]* On
© 2024.09
Change during operation:
Description
Select [0] Off when more MCOs are connected to the same
absolute encoder. Only 1 MCO is allowed to generate the clock
signal when multiple MCOs are interconnected.
Select [1] On when 1 MCO is connected to 1 absolute encoder.
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
Parameter type:
Conversion index:
Change during operation:
Description
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
True
Range, 0 - 300 m
0
True
Option
–
True
Option
–
True
