Programming Guide | VLT® AutomationDrive FC 301/FC 302
5-11 Terminal 19 Digital Input
Default value: Size related
Setup: All setups
Data type: Uint8
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
5-12 Terminal 27 Digital Input
Default value: Size related
Setup:
All setups
Data type: Uint8
Option Name
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
220 | © 2024.09
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
Parameter Descriptions
Option
–
True
Option
–
True
