Programming Guide | VLT® AutomationDrive FC 301/FC 302
Setup:
All setups
Data type:
Int32
View the actual value of the frequency applied at terminal 33 as an impulse input.
16-69 Pulse Output #27 [Hz]
Default value:
0
Setup:
All setups
Data type:
Int32
View the actual value of pulses applied to terminal 27 in digital output mode.
16-70 Pulse Output #29 [Hz]
Default value:
0
Setup:
All setups
Data type:
Int32
View the actual value of pulses at terminal 29 in digital output mode.
16-71 Relay Output [bin]
Default value:
0
Setup:
All setups
Data type:
Int16
View the settings of all relays.
Readout choice (P16-71):
Relay output (bin):
Figure 92: Relay Settings
16-72 Counter A
Default value:
0
Setup:
All setups
Data type:
Int32
© 2024.09
00000 bin
OptionB card relay 09
OptionB card relay 08
OptionB card relay 07
Power card relay 02
Power card relay 01
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
0
False
Range, 0 - 40000
0
False
Range, 0 - 40000
0
False
Range, 0 - 511
0
False
Range, -2147483648 -
2147483647
0
True
569
