Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 3: Local Control Keys and Description
LCP keys
[Auto On]
[Reset]
5.1.4

Quick Transfer of Parameter Settings between Multiple Drives

When setup of a drive is completed, store the data in the LCP. Then connect the LCP to another drive and copy the parameter settings to
the new drive.

Transferring Data

5.1.5

Transferring Data from the Drive to the LCP

5.1.5.1
1.
Go to parameter 0-50 LCP Copy.
2. Press [OK]
3. Select [1] All to LCP.
4.
Press [OK].

Transferring Data from the LCP to the Drive

5.1.5.2
1.
Go to parameter 0-50 LCP Copy.
2. Press [OK].
3.
Select [2] All from LCP.
4.
Press [OK].

Display Mode

5.1.6
In normal operation, up to 5 different operating variables can be indicated continuously in the middle section: 1.1, 1.2, and 1.3, as well as
2 and 3.

Display Mode - Selection of Readouts

5.1.7
It is possible to toggle between 3 status readout screens by pressing [Status].
Operating variables with different formatting are shown in each status view (status view I, status view II, and status view III).
© 2024.09
(continued)
Description
Enables the drive to be controlled via the control terminals and/
or serial communication.
When a start signal is applied on the control terminals and/or the
bus, the drive starts. The key can be selected as [1] Enable or [0]
Disable via parameter 0-42 [Auto On] Key on LCP.
NOTICE
An active HAND-OFF-AUTO signal via the digital inputs
has higher priority than the control keys [Hand On] –
[Auto On].
Use [Reset] for resetting the drive after an alarm (trip). It can be
selected as [1] Enable or [0] Disable via parameter 0-43 [Reset]
Key on LCP.
The parameter shortcut can be carried out be pressing down the
[Main Menu] key for 3 s. The parameter shortcut provides direct
access to any parameter.
AU275636650261en-003201 / 130R0334 |
How to Program
31
