7-0* Speed PID Ctrl.

6.9.3
If separate encoders are used (FC 302 only), adjust the ramp-related parameters according to the gear ratio between the 2
encoders.
7-00 Speed PID Feedback Source
Default value:
–
Setup: All setups
Data type:
Uint8
Option Name
[0] Motor feedb. P1-02
[1] 24V encoder 32/33
[2] MCB 102
[3] MCB 103
[4] MCO Encoder 1 X56
[5] MCO Encoder 2 X55
[6] Analog input 53
[7] Analog input 54
[8] Frequency input 29
302 | © 2024.09
NOTICE
Parameter type:
Conversion index:
Change during operation:
Description
This option is only available FC 302.
Use the feedback source selected as motor feedback in
parameter 1-02 Flux Motor Feedback Source.
Single signal generated from 24 V High Threshold Logic (HTL)
encoder connected to terminals 32 and 33. Configure the 24 V
encoder interface in parameter group 5-7* 24V Encoder Input.
Program terminals 32/33 to [0] No operation.
This is only available for VLT® Encoder Option MCB 102. Configure
the encoder interface in parameter groups 17-0*, 17-1*, and 17-2*.
This is only available for VLT® Resolver Option MCB 103.
Configure the resolver interface in parameter group 17-5* Resolver
Interface.
The MCO encoder 1 X56 is only available with motion control
options MCO 305, MCO 350, and MCO 351. Configure the
encoder interface in parameter group 32-3* Encoder 1.
The MCO encoder 1 X56 is only available with motion control
options MCO 305, MCO 350, and MCO 351. Configure the
encoder interface in parameter group 32-0* Encoder 2.
Feedback source from analog input 53.
Feedback source from analog input 54.
This option is only available FC 302.
Feedback source from frequency input 29.
