Programming Guide | VLT® AutomationDrive FC 301/FC 302
5-02 Terminal 29 Mode
Default value: –
Setup: All setups
Data type: Uint8
Option Name
[0] Input
[1] Output

5-1* Digital Inputs

6.7.2
The following parameter is only available in FC 302:
Parameter 5-13 Terminal 29 Digital Input
l
The digital inputs are used for selecting various functions in the drive. Refer to
inputs.
Functions in function group 1 have higher priority than functions in function group 2.
Table 23: Function Groups
Group
1
2
Table 24: Digital Input Functions and Terminals
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC brake inverse
Stop inverse
Start
Latched start
Reversing
200 | © 2024.09
Parameter type:
Conversion index:
Change during operation:
Description
Defines terminal 29 as a digital input.
Defines terminal 29 as a digital output.
NOTICE
Functions
Reset, coast stop, reset and coast stop, quick stop, DC brake, stop,
and the [Off ] key.
Start, latched start, reversing, start reversing, jog, and freeze out-
put.
Select
[0]
[1]
[2]
[3]
[4]
[5]
[6]
[8]
[9]
[10]
Option
–
True
Table 24 for functions which can be assigned to digital
Terminal
All, terminal 32, 33
All
All, terminal 27
All
All
All
All
All, terminal 18
All
All, terminal 19
AU275636650261en-003201 / 130R0334
Parameter Descriptions
