Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[221] IGBT-cooling
[222] Homing OK
[223] On target
[224] Position limit
[225] Position error
[226] Touch on target
[227] Touch activated
[231] In power lim. mot.
[232] In power lim. gen.
[233] In power limit
[234] PE power off
[246] Emergency mode was act.
[247] Emergency mode
[249] Emcy m. OPR unexpected
[250] Emcy mode limits
[254] Testing emcy mode
36-42 Terminal X49/7 Min Scale
Default value: 0%
Setup:
All setups
Data type: Int16
Match the minimum output of terminal X49/7 with a required value. The required value is defined as a percentage of the value selected
in parameter 36-40 Terminal X49/7 Analogue Output. To know more about how this parameter works, see parameter 6-52 Terminal 42
Output Max Scale. The following example describes how the drive uses this parameter.
Example:
Parameter 36-03 Terminal X49/7 Mode = [0] Voltage 0–10 V.
l
Parameter 36-40 Terminal X49/7 Analogue Output = [100] Output frequency.
l
Parameter 4-19 Max Output Frequency = 200 Hz.
l
© 2024.09
Description
Parameter type:
Conversion index:
Change during operation:
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Range, 0 - 200%
-2
True
