Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 7: LCP Keys and Description
LCP keys
[Back]
Navigation keys
[OK]
Local control keys: Local control keys are at the bottom of the control panel.
Table 8: Local Control Keys and Description
LCP keys
[Hand On]
[Off ]
44 | © 2024.09
(continued)
Description
Returns to the previous step or layer in the navigation structure.
The 2 navigation keys are used to navigate between the different options available in
Quick Menu and Main Menu. Press the keys to move the cursor.
Press to select a parameter marked by the cursor and to enable the change of a parame-
ter.
Description
Enables control of the drive via the LCP.
[Hand On] also starts the motor, and it is now possible to enter
the motor speed data with the navigation keys. The key can be
selected as [1] Enable or [0] Disable via parameter 0-40 [Hand
on] Key on LCP.
External stop signals activated with control signals or a fieldbus
override a start command via the LCP.
The following control signals are still active when [Hand On] is ac-
tivated:
• [Hand On] - [Off ] - [Auto On]
• Reset
• Coast stop inverse
• Reversing
• Setup select lsb - Setup select msb
• Stop command from serial communication
• Quick stop
• DC brake
Stops the connected motor. The key can be selected as [1] Enable
or [0] Disable via parameter 0-41 [Off] Key on LCP.
If the external stop function is not selected and the [Off] key is in-
active, the motor can be stopped by disconnecting the voltage.
How to Program
