Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[3] Set-up 3
[4] Set-up 4
Example
Use multi set-up to shift from setup 1 to setup 2 while the motor is running. Program in setup 1 first, then ensure that setup 1 and setup 2
are synchronized (or linked). Synchronization can be performed in 2 ways:
Select the following options:
l
[2] Set-up 2 in parameter 0-11 Edit Set-up
¢
Set parameter 0-12 This Set-up Linked to to [1] Set-up 1.
¢
0 RPM
Set-up Handling
0-12 This Set-up Linked to
[1] Setup 1
Figure 28: Setup 1
While still in setup 1, copy setup 1 to setup 2. Then set parameter 0-12 This Set-up Linked to to [2] Set-up 2.
l
0 RPM
Set-up Handling
0-12 This Set-up Linked to
[2] Setup 2
Figure 29: Setup 2
0-13 Readout: Linked Set-ups
Default value: 0
Setup:
All setups
Data type: Uint16
View a list of all the setups linked by parameter 0-12 This Set-up Linked to. The parameter has 1 index for each parameter setup. The
value for each index shows which setups are linked to that parameter setup.
52 | © 2024.09
0.00A 1(1)
0-1*
0.00A 1(1)
0-1*
Description
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
Range, 0 – 255, Array [5]
0
False
AU275636650261en-003201 / 130R0334
