Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[14] MCB 102 Absolute
[15] MCO Encoder 1 X56
[16] MCO Encoder 2 X55
[20] Digital Potmeter
[21] Analog Input X30/11
[22] Analog Input X30/12
[29] Analog Input X48/2
[37] Analog Input X49/1
[38] Analog Input X49/3
[39] Analog Input X49/5
3-17 Reference Resource 3
Default value: –
Setup: All setups
Data type: Uint8
Select the reference input to be used for the 3rd reference signal. Parameter 3-15 Resource Reference 1, parameter 3-16 Resource
Reference 2, and parameter 3-17 Resource Reference 3 define up to 3 different reference signals. The sum of these reference signals
defines the actual reference.
Option Name
[0] No function
[1] Analog Input 53
[2] Analog Input 54
[3] 24V Encoder 32/33
[4] MCB 102
[5] MCB 103
[6] Virtual Master
[7] Frequency Input 29
[8] Frequency Input 33
[11] Local Bus Reference
[12] Preset Reference
154 | © 2024.09
Description
The option is only available for VLT® Encoder Option MCB
102 with version 4.00 and newer and when parameter 17-00
Encoders Connected is set to option [1] Two Encoders.
VLT® General Purpose I/O MCB 101
VLT® General Purpose I/O MCB 101
Parameter type:
Conversion index:
Change during operation:
Description
NOTICE
This option is only available in FC 302.
Reference from terminals 68 and 69.
Parameter Descriptions
Option
–
True
