Programming Guide | VLT® AutomationDrive FC 301/FC 302
Setup: All setups
Data type: Uint8
This parameter cannot be adjusted while the motor is running.
Option Name
[0]* None
[1] HIPERFACE
[2] EnDat
[4] SSI
[8] Z pulse
17-21 Resolution (Positions/Rev)
Default value: Size related
Setup:
All setups
Data type: Uint32
Select the resolution of the absolute encoder, that is the number of counts per revolution. The value depends on setting in parameter
17-20 Protocol Selection.
17-22 Multiturn Revolutions
Default value:
1
Setup: All setups
Data type:
Uint32
Select the number of multi-turn revolutions. Select value 1 for single-turn type encoders.
17-24 SSI Data Length
Default value: 13
Setup: All setups
Data type: Uint8
Set the number of bits for the SSI telegram. Select 13 bits for singleturn encoders and 25 bits for multiturn encoders.
17-25 Clock Rate
Default value: 260 kHz
Setup:
All setups
578 | © 2024.09
Conversion index:
Change during operation:
NOTICE
Description
Select [0] None if the feedback sensor is an incremental encoder
only.
Select [1] HIPERFACE if the encoder is absolute only.
Select 0 pulse as "absolute" track when using incremental
encoder with 0 pulse.
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index.
Parameter Descriptions
–
False
Range, 4 - 1073741824
0
True
Range, 1 - 16777216
0
False
Range, 1 - 32
0
False
Range, 100 - 260 kHz
3
