Programming Guide | VLT® AutomationDrive FC 301/FC 302
1-99 ATEX ETR Interpol. Points Current
Default value: Size related
Setup: 2 setups
Data type: Uint16
Definition of the thermal limitation curve. For example, see parameter 1-98 ATEX ETR Interpol. Points Freq.
Interpolation points
x-axis: f [Hz]
m
y-axis: I /I x 100 [%]
m m,n
Table 17: Interpolation Points
Parameter 1-98 ATEX ETR Interpol. Points Freq.
[0]=5 Hz
[1]=15 Hz
[2]=25 Hz
[3]=50 Hz
Use the 4 current points [A] from the motor nameplate. Calculate the values as a percentage of nominal motor current, I
and enter the values into the array. All operating points underneath the curve are allowed continuously. Above the line, however, these
points are only allowed for a limited time calculated as a function of the overload. When machine current is greater than 1.5 times the
rated current, shutdown is immediate.
All frequency/current limit points from the motor nameplate of motor datasheet must be programmed.
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Parameter 1-99 ATEX ETR Interpol. Points Current
[0]=40%
[1]=80%
[2]=100%
[3]=100%
NOTICE
Parameter Descriptions
Range, 0 - 100%, Array [4]
0
True
/I
m m,n
AU275636650261en-003201 / 130R0334 |
x 100 [%],
