Programming Guide | VLT® AutomationDrive FC 301/FC 302
The 2 operators can be selected from a long list. As a special case, the same digital input can be used as both set and reset, making it
possible to use the same digital input as start/stop. The following settings can be used to set up the same digital input (for example,
DI32) as start/stop.
Table 45: Operators
Parameter
Parameter 13-00 SL Controller Mode
Parameter 13-01 Start Event [0]
Parameter 13-02 Stop Event [0]
Parameter 13-40 Logic Rule Boolean 1 [0]
Parameter 13-42 Logic Rule Boolean 2 [0]
Parameter 13-41 Logic Rule Operator 1 [0]
Parameter 13-40 Logic Rule Boolean 1 [1]
Parameter 13-42 Logic Rule Boolean 2 [1]
Parameter 13-41 Logic Rule Operator 1 [1]
Parameter 13-15 RS-FF Operand S [0]
Parameter 13-16 RS-FF Operand R [0]
Parameter 13-51 SL Controller 1 Event [0]
Parameter 13-52 SL Controller 1 Action [0]
Parameter 13-51 SL Controller 1 Event [1]
Parameter 13-52 SL Controller 1 Action [1]
13-15 RS-FF Operand S
Default value: –
Setup:
2 setups
Data type: Uint8
© 2024.09
Setting
[1] On
True
False
[37] Digital input DI32
[2] Running
[3] AND NOT
[37] Digital input DI32
[2] Running
[1] AND
[26] Logic rule 0
[27] Logic rule 1
[94] RS Flipflop 0
[22] Run
[27] Logic rule 1
[24] Stop
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
Notes
–
–
–
–
–
–
–
–
–
Output from parameter 13-41 Logic Rule
Operator 1 [0].
Output from parameter 13-41 Logic Rule
Operator 1 [1].
Output from parameter 13-15 RSFF
Operand S and parameter 13-16 RSFF
Operand R.
–
–
–
Option, Array [10]
–
True
