Programming Guide | VLT® AutomationDrive FC 301/FC 302
Data type: Int32
This parameter is only available with software version 48.XX.
Velocity reference when running cyclic sync. velocity mode.
6.18.5 17-5* Resolver Interface
This parameter group is used for setting parameters for the VLT® Resolver Input MCB 103. Usually, the resolver feedback is used as motor
feedback from permanent magnet motors with parameter 1-01 Motor Control Principle set to [3] Flux w/motor feedback. Resolver
parameters cannot be adjusted while the motor is running.
17-50 Poles
Default value:
2
Setup: 1 setup
Data type:
Uint8
Set the pole number on the resolver. The value is stated in the datasheet for resolvers.
17-51 Input Voltage
Default value: 7 V
Setup: 1 setup
Data type: Uint8
Set the input voltage to the resolver. The voltage is stated as RMS value. The value is stated in the datasheet for resolvers.
17-52 Input Frequency
Default value: 10 kHz
Setup:
1 setup
Data type: Uint8
Set the input frequency to the resolver. The value is stated in the datasheet for resolvers.
17-53 Transformation Ratio
Default value: 0.5
Setup: 1 setup
Data type: Uint8
Set the transformation ratio for the resolver. The transformation ratio is:
The value is stated in the datasheet for resolvers.
© 2024.09
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
True
Range, 2 - 64
0
False
Range, 2 - 8 V
-1
False
Range, 2 - 15 kHz
2
False
Range, 0.1 - 1.1
-1
False
