Programming Guide | VLT® AutomationDrive FC 301/FC 302
Data type: Int32
Enter the reference or feedback value (in RPM, Hz, bar, and so on) corresponding to the voltage or current set in parameter 36-30
Terminal X49/5 Low Voltage or parameter 36-31 Terminal X49/4 Low Current.
36-35 Terminal X49/5 High Ref./Feedb. Value
Default value: 100 ReferenceFeedbackUnit
Setup: All setups
Data type: Int32
Enter the reference or feedback value (in RPM, Hz, bar, and so on) corresponding to the voltage or current set in parameter 36-32
Terminal X49/5 High Voltage or parameter 36-33 Terminal X49/5 High Current.
36-36 Term. X49/5 Filter Time Constant
Default value: 0.001 s
Setup:
All setups
Data type: Uint16
Enter the filter time constant. This is a first-order digital low-pass filter time constant for suppressing electrical noise in terminal X49/5. A
high time constant value improves dampening but also increases the time delay through the filter.
36-4* Output X49/7
6.35.5
The following parameter is only available in FC 302:
Parameter 36-41 Terminal X49/7 Digital Output
l
Use the parameters in this group to configure the mode of inputs and outputs of VLT® Programmable I/O MCB 115.
36-40 Terminal X49/7 Analogue Output
Default value: [0] No operation
Setup:
All setups
Data type: Uint8
Select the functionality of terminal X49/7.
Option Name
[0]* No operation
[52] MCO
[100] Output frequency
712 | © 2024.09
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
NOTICE
Parameter type:
Conversion index:
Change during operation:
Description
Indicates no signal on the analog output.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter Descriptions
True
Range, -999999.999 -
999999.999
0
True
Range, 0.001 - 10 s
0
True
Option
–
True
