Programming Guide | VLT® AutomationDrive FC 301/FC 302
Table 35: 5-30 Digital Outputs - 2
Option
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[221] IGBT cooling
[222] Homing OK
[223] On target
[224] Position limit
[225] Position error
[226] Touch on target
© 2024.09
(continued)
Function
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
Use this option for handling the overcurrent trips. When the drive
detects an overcurrent condition, it shows alarm 13, Overcurrent
and triggers a reset. If the overcurrent condition occurs for the 3
time in a row, the drive shows alarm 13, Overcurrent and initiates
a 3-minute delay before the next reset.
NOTICE
This option is only available with software version 48.XX.
Homing is completed with the selected homing function in
parameter 17-80 Homing Function.
NOTICE
This option is only available with software version 48.XX.
Positioning is completed and the on-target signal is sent when
the actual position is within parameter 3-05 On Reference
Window for the duration of parameter 3-09 On Target Time and
the actual speed does not exceed parameter 3-05 On Reference
Window.
NOTICE
This option is only available with software version 48.XX.
The position error exceeds the value in parameter 4-71
Maximum Position Error for the time set in parameter 4-72
Position Error Timeout.
NOTICE
This option is only available with software version 48.XX.
The position is outside the limits set in parameter 3-06 Minimum
Position and parameter 3-07 Maximum Position.
NOTICE
This option is only available with software version 48.XX.
The target position is reached in touch probe position mode.
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
