Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[2] >
[5] TRUE longer than..
[6] FALSE longerthan..
[7] TRUE shorter than..
[8] FALSE shorter than..
13-12 Comparator Value
Default value: Size related
Setup: 2 setups
Data type:
Int32
Enter the trigger level for the variable that is monitored by this comparator. This is an array parameter containing comparator values 0–9.

13-1* RS Flip Flops

6.14.4
The reset/set flip flops hold the signal until set/reset.
Parameter 13-15
RS-FF Operand S
Parameter 13-16
RS-FF Operand R
Figure 81: Reset/Set Flip Flops
Two parameters are used and the output can be used in the logic rules and as events.
S
R
Flip flop output
Figure 82: Flip Flop Outputs
434 | © 2024.09
Description
NOTICE
If [20] Alarm number or [21] Warning number is selected
in parameter 3-10 Comparator Operand, [2] > cannot be
selected in this parameter.
Inverse logic of option [0] <.
Parameter type:
Conversion index:
Change during operation:
Parameter Descriptions
Range, -10000.000 - 100000,
Array [10]
-3
True
AU275636650261en-003201 / 130R0334
