Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input AI53
[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input X30/11
© 2024.09
Description
The value is in %.
The value is in %.
The value is in %.
The value is in %.
The value is in %.
AIFB10 is internal 10 V supply.
AIS24V is a 24 V switch mode power supply.
Value is in [°]. AICCT is control card temperature.
NOTICE
This option is only available in FC 302.
The value is in %.
The value is in %.
Shows the actual alarm number.
NOTICE
With this selection, it is not possible to use < and > as
comparator operators.
NOTICE
Several alarms/warnings can be present at the same time.
As the alarm/warning numbers are not grouped in a
predefined order, defining a range is not relevant.
Shows the actual warning number.
NOTICE
With this selection, it is not possible to use < and > as
comparator operators.
NOTICE
Several alarms/warnings can be present at the same time.
As the alarm/warning numbers are not grouped in a
predefined order, defining a range is not relevant.
