Programming Guide | VLT® AutomationDrive FC 301/FC 302
15-17 Service Log Trigger Alarm
Default value: 0
Setup: All setups
Data type: Uint16
Enter alarm number that triggers the Service Log write to flash. By default Service Log will log motor specific data during motor related
alarms. Using Displayline parameters 0-20 Display Line 1.1 Small, 0-21 Display Line 1.2 Small, and 0-22 Display Line 1.3 small with current
parameter, the Service Log can be configured for custom data logging events.
15-18 Service Log Trigger SLC
Default value: [0] False
Setup:
All setups
Data type: Uint8
The service log can be used for troubleshooting. The SLC operands trigger the service log when an event occurs. The maximum numbers
of service logs is 24. To clear the service logs, use parameter 14-22 Operation Mode followed by a power cycle.
Option Name
[0]* False
[18] Reversing
[19] Warning
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[30] SL time-out 0
[31] SL time-out 1
[32] SL time-out 2
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Description
NOTICE
This option is only available in FC 302.
AU275636650261en-003201 / 130R0334 |
Parameter Descriptions
Range, 0=Off - 9999
-3
True
Option
–
True
