Programming Guide | VLT® AutomationDrive FC 301/FC 302
Option Name
[2] Clear at coast running
[3] Clear at homing only
17-87 Homing Activation
Default value: [0] Manual
Setup:
All setups
Data type: Uint8
This parameter is only available with software version 48.XX.
Activation manner of drive homing and master homing. Master homing can be activated by a Set Master Home signal or the Start Homing
signal by selecting options [2] Manual and Master and [3] Auto and Master.
Option Name
[0]* Manual
[1] Auto
[2] Manual and master
[3] Auto and master
17-88 Master Home Position
Default value: 0 AbsolutePositionUnit
© 2024.09
Description
Homing Ok is cleared at motor coast only while motor is running
and a new homing is needed. The option is a typical selection for
sensorless control with a mechanical brake holding the position
at stand still.
Homing Ok is only cleared at new start of the selected homing
function. The option is a typical selection for absolute encoders.
After completing the selected homing function Parameter 17-74
Position Offset is automatically set to the offset calculated by:
Parameter 17-74 Position Offset = (Parameter 17-82.0 Home
Position) - (Position value read from encoder). Start a new
homing to re-calculate Parameter 17-74 Position Offset, for
example, after replacing the encoder.
Parameter type:
Conversion index:
Change during operation:
NOTICE
Description
Activates homing function selected in parameter 17-80 Homing
Function using the Start Homing signal.
Homing function selected in parameter 17-80 Homing Function
is activated automatically when the Homing OK signal is low and
start signal is applied.
Activates homing function selected in parameter 17-80 Homing
Function and sets the actual master position as defined in
parameter 17-88 Master Home Position, using Start Homing
signal.
Homing function selected in parameter 17-80 Homing Function
is activated automatically when the Homing OK signal is low and
start signal is applied. The actual master position is set as defined
in parameter 17-88 Master Home Position.
Parameter type:
Parameter Descriptions
Option
–
True
Range, -2147483648
- 2147483647
AbsolutePositionUnit
