6-53 Term 42 Output Bus Ctrl
Default value: 0%
Setup: All setups
Data type: N2
Holds the level of output 42 if controlled by bus.
6-54 Term 42 Output Timeout Preset
Default value: 0%
Setup:
1 setup
Data type: Uint16
Holds the preset level of output 42. If a timeout function is selected in parameter 6-50 Terminal 42 Output, the output is preset to this
level if a fieldbus timeout occurs.
6-55 Analog Output Filter
Default value: [0] Off
Setup: 1 setup
Data type: Uint8
The following readout parameters from selection in parameter 6-50 Terminal 42 Output have a filter selected when parameter 6-55
Analog Output Filter is on.
Table 39: Readout Parameters
Selection
Motor current (I )
max
Torque limit (0–T )
lim
Rated torque (0–T )
nom
Power (0–P
nom)
Speed (0–Speed )
max
Option Name
[0]* Off
[1] On
6.8.7

6-6* Analog Output 2 MCB 101

Analog outputs are current outputs: 0/4–20 mA. Common terminal (terminal X30/8) is the same terminal and electrical potential for
analog common communication. The resolution on analog output is 12 bit.
© 2024.09
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
Parameter type:
Conversion index:
Change during operation:
0–20 mA
[103]
[104]
[105]
[106]
[107]
Description
Filter off.
Filter on.
Parameter Descriptions
Range, 0 - 100%
-2
True
Range, 0 - 100%
-2
True
Option
–
True
4–20 mA
[133]
[134]
[135]
[136]
[137]
